Halliburton HT400 plunger pump seals, SPM TWS600 plunger pump, TWS2250 Plunger pump, Gardner Denver 2250 plunger pump

Name: Halliburton HT400 plunger pump seals SPM TWS600 plunger pump TWS2250 Plunger pump Gardner Denver 2250 plunger pump
Brand: Halliburton,
Price: 1 USD

Quality Halliburton HT400 plunger pump seals, SPM TWS600 plunger pump, TWS2250 Plunger pump, Gardner Denver 2250 plunger pump wholesale

Brand Name : Halliburton,

Model Number : HT400

Certification : API

Place of Origin : CHINA

MOQ : 1 piece

Price : 1 to 500 usd

Payment Terms : T/T, D/A, D/P, L/C, Western Union

Supply Ability : 10000 PER MONTH

Delivery Time : In stock

Packaging Details : Suitable to shipment by sea and air

Usage : Oil,Water,drill rig

Power : Electric,Hydraulic

Pressure : High Pressure

Application : mining,oil,Chemical

Structure : Piston Pump

Fuel : Diesel

Standard or nonstandard : Standard

Type : Mud Pump

Color : red and so on

Material : cast iron/stainless steel mud suction pump

Warranty : 12 Months

Product name : Mud Pump

Oem : can be accept

Condition : new

Contact Now

Halliburton HT400 plunger pump seals, SPM TWS600 plunger pump, TWS2250 Plunger pump, Gardner Denver 2250 plunger pump

Push Rod Subassembly
L-2 Spacer
	Loc	Part No.
Retainer,Push Rod HT-400TM, Two Piece Nose, L-Spacer	1	316.21066.
O-Ring, 90 Duro, 1 7/8 × 1 5/8 × 1/8, 568-223	2	8.34020.
Tie Rod, Push Rod, L-Spacer, HT-400TM	3	316.25166.
Push Rod, Two Piece, L-Spacer, HT-400TM	4	316.21065.
Retainer, Push Rod Seal Housing, L-2 Spacer, HT-400TM	5	316.10012.
Housing, Push Rod Seal, Floating, L-2 Spacer, HT-400TM	6	316.10013.
O-Ring, 70 Duro, 5 11/16 × 5 1/2 × 3/32, 568-161	7	70.33739.
Seal, Push Rod, L-Spacer, HT-400TM	8	316.10014.

Discharge Valve Subassembly
		Plunger Size
	Loc	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Retainer, Cover, HT-400TM	1	316.2102.	316.2202.	316.2202.	316.2502.	316.2502.
Cover, Discharge, Double Guided Valve, HT-400TM	2	316.2107.	316.23091.	316.23091.	316.24044	316.24044
Gasket, Discharge Valve & Cylinder Head Cover, HT-400TM	3	316.21052.	316.22052.	316.22052.	316.25052	316.25052
Ring, Spacer, Discharge Valve & Cylinder Head Cover, HT-400TM	4	316.21051.	316.22051.	316.22051.	316.25051.	316.25051.
Liner, Two Piece Bushing, Valve Guide, HT-400, Brass	5	316.22005.	316.22005.	316.22005.	316.22007.	316.22007.
Insert, Two Piece Bushing, Valve Guide, Special, HT-400	6	316.22004.	316.22004.	316.22004.	316.22006	316.22006
Spring, Valve, HT-400TM, 36lb/in	7	316.2108.	316.2108.	316.2308.	316.27259	316.27259
Valve, HT-400, Frac	8	316.21007.	316.21007.	316.22048.	316.24027	316.24027
Insert, Valve, HT-400TM, Urethane, Acid/Frac Service(Yellow)	9	316.21048.	316.21048.	316.22046.	316.24026	316.24026
Insert, Valve, HT-400TM, Urethane, Standard Service(Brown)	9	316.21006.	316.21006.	316.22049.	316.24037	316.24037
Seat Valve, HT-400TM, Tapered	10	316.21008.	316.21008.	316.210047.	316.24024	316.24024
O-ring, 90 Duro	11	8.34037.	8.34037.	8.34041.	8.34045	8.34045
Retainer, Guide Bushing, HT400	12	316.21096	316.21096	316.23953	316.24043	316.24043

Suction Valve Subassembly
		Plunger Size
	Loc	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Retainer, Stop and Spring, HT-400TM, Mach. Cast	1	316.22977.	316.22977.	316.23034	316.25840.	316.25840.
Boot, Suction and Stop, HT-400TM	2	316.25233.	316.25233.	316.25233	316.25233.	316.25233.
Spring, Lock, HT-400	3	316.2125.	316.2125.	316.22252.	316.22253.	316.22253.
Liner, Two Piece Bushing, Valve Guide, HT-400TM, Brass	4	316.22005.	316.22005.	316.22005.	316.22007.	316.22007.
Insert,Two Piece Bushing, Valve Guide, Special,HT-400TM	5	316.22004.	316.22004.	316.22004.	316.22006.	316.22006.
Spring, Valve, HT-400TM, 36lb/in	7	316.2108.	316.2108.	316.2308.	316.27259	316.27259
Valve, HT-400, Frac	8	316.21007.	316.21007.	316.22048.	316.24027	316.24027
Insert, Valve, HT-400TM, Urethane, Acid/Frac Service(Yellow)	9	316.21048.	316.21048.	316.22046.	316.24026	316.24026
Insert, Valve, HT-400TM, Urethane, Standard Service(Brown)	9	316.21006.	316.21006.	316.22049.	316.24037	316.24037
Seat Valve, HT-400TM, Tapered	10	316.21008.	316.21008.	316.210047.	316.24024	316.24024
O-ring, 90 Duro	11	8.34037.	8.34037.	8.34041.	8.34045	8.34045
Retainer, Guide Bushing, HT400	12	316.21096	316.21096	316.23953	316.24043	316.24043


Plunger/cylender Head Cover Subassembly
		Plunger Size
	Loc	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Retainer, Cover HT-400TM	1	316.2102.	316.2102.	316.2202.	316.2502.	316.2506.
Cover, Cylinder Head, HT-400TM	2	316.2107.	316.2107.	316.2207.	316.2407.	316.2507.
Gasket, 4 Discharge Valve & Cylinder Head Cover	3	316.21052.	316.21052.	316.22052.	316.25052.	316.25074.
Ring, Spacer, Discharge Valve & Cylinder Head Cover	4	316.21051.	316.21051.	316.22051.	316.25051.	316.25073.
Nose, Plunger, HT-400TM	5	316.2131.	316.2231.	316.2331.	316.2331.	316.2331.
Seal, Plunger Nose Assembly, HT-400TM	6	316.2130.	316.2230.	316.2330.	316.2330.	316.2330.
Plunger, Hard Surface, L-Spacer, HT-400TM	7	316.21026.	316.22294.	316.23085.	316.24296.	316.25162.
Tie Rod, Plunger, HT-400TM	8	316.21028.	316.21028.	316.21028.	316.25165.	316.25165.
Adapter, Pushrod, HT-400TM, Two Piece Nose	9	316.21059.	316.22302.	316.23089.	316.24336.	316.25172.


Fluid-end/flange discharge section subassembly
		Plunger Size
	Loc	3-3/8 inch	4-inch	4-1/2 inch
Flange, discharge, HT-400TM, BLANK	1		316.22980.	316.22980.
Flange, discharge, HT-400TM, CURVED, Rright Hand	1a	316.21676.	316.23019.	316.23019.
Flange, discharge, HT-400TM, CURVED, Left Hand	1b	316.21677.	316.23017.	316.23017.
Seal, Discharge passage,HT-400TM	2	315.27117.	316.2547.	316.2547.
Nut, 1-14NF, Internal Wrenching, 1.03 TL	3	316.11621.	316.11621.	316.11621.
Stud, HT-400TM Fluid End To Thick Discharge Flange	4	316.23013.		316.23013.
Bolt, Tie, 1.375-12 UNF×32.4 in.,Top, Fluid End, HT-400TM, TC	5	316.27488.	316.27488.	316.27488.
Nut, Top Tie Bolt, HT-400TM, TC	6	316.25501.	316.25501.	316.25501.
Washer, Hardened,2.31 O.D ×1.43I.D.,For Top Tie Boldt,	7	316.22493.	316.22493.	316.22493.
Spacer, Inner, Discharge Passage Seal,HT-400TM	8	316.2145.	316.2545.	316.2545.
Fluid End Section, HT-400TM PUMP,Not Sleeved	9	316.21951.	316.22982.	316.23951.
Nut, Elastic, Stop,3/4-in.,16 NF	10	70.32760.		70.32760.

Packing Subassembly
		Plunger Size
	Loc	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Adapter, Header	1	316.21503	316.22503	316.23503	316.24503	316.27503
Ring Header	2	316.21501	316.22501	316.23501	316.24501	316.27501
Packign Set, 4-in.x 5-in, x 1/2-in. Stock, 3 Rings, Hard, Acid Service	3	316.21525	316.22525	316.23525	316.24525	316.27525
Ring, Backup, Packing, 4-in x 5-in.	4	316.21393	316.22393	316.23393	316.24393	316.27393
Carrier, Seal and Packing, 4-in	5	316.21396	316.22396	316.23396	316.24396	316.27396
Seal, Lube, Packing, WQ, 4-in x 4-1/2-in. x 9/16-in	6	316.21395	316.22395	316.23395	316.24395	316.27395
O-Ring, 90D, 5-in. x 4 3/4-in.x 1/8-in	7	8.34040	8.34045	8.34049	8.34053	8.34058

Halliburton HT400 plunger pump seals, SPM TWS600 plunger pump, TWS2250 Plunger pump, Gardner Denver 2250 plunger pump

Founded in 1919, Halliburton is one of the world's largest providers of products and services to the energy industry. With approximately 60,000 employees, representing 140 nationalities in more than 80 countries, the company helps its customers maximize value throughout the lifecycle of the reservoir – from locating hydrocarbons and managing geological data, to drilling and formation evaluation, well construction and completion, and optimizing production throughout the life of the asset.

Push Rod Subassembly
L-2 Spacer
	Loc	Qty	Part No.
Retainer,Push Rod HT-400TM, Two Piece Nose, L-Spacer	1	3	316.21066.PREM
O-Ring, 90 Duro, 1 7/8 × 1 5/8 × 1/8, 568-223	2	3	8.34020.PREM
Tie Rod, Push Rod, L-Spacer, HT-400TM	3	3	316.25166.PREM
Push Rod, Two Piece, L-Spacer, HT-400TM	4	3	316.21065.PREM
Retainer, Push Rod Seal Housing, L-2 Spacer, HT-400TM	5	3	316.10012.PREM
Housing, Push Rod Seal, Floating, L-2 Spacer, HT-400TM	6	3	316.10013.PREM
O-Ring, 70 Duro, 5 11/16 × 5 1/2 × 3/32, 568-161	7	3	70.33739.PREM
Seal, Push Rod, L-Spacer, HT-400TM	8	6	316.10014.PREM

Discharge Valve Subassembly
Plunger Size
	Loc	Qty	3-3/8 inch	4-inch	4-1/2 inch
Retainer, Cover, HT-400TM	1	3	316.2102.PREM	316.2202.PREM	316.2202.PREM
Cover, Discharge, Double Guided Valve, HT-400TM	2	3	316.2107.PREM	316.23091.PREM	316.23091.PREM
Gasket, Discharge Valve & Cylinder Head Cover, HT-400TM	3	3	316.21052.PREM	316.22052.PREM	316.22052.PREM
Ring, Spacer, Discharge Valve & Cylinder Head Cover, HT-400TM	4	3	316.21051.PREM	316.22051.PREM	316.22051.PREM
Liner, Two Piece Bushing, Valve Guide, HT-400, Brass	5	6	316.22005.PREM	316.22005.PREM	316.22005.PREM
Insert, Two Piece Bushing, Valve Guide, Special, HT-400	6	6	316.22004.PREM	316.22004.PREM	316.22004.PREM
Spring, Valve, HT-400TM, 36lb/in	7	3	316.2108.PREM	316.2108.PREM	316.2308.PREM
Valve, HT-400, Frac	8	3	316.21007.PREM	316.21007.PREM	316.22048.PREM
Insert, Valve, HT-400TM, Urethane, Acid/Frac Service(Yellow)	9	3	316.21048.PREM	316.21048.PREM	316.22046.PREM
Insert, Valve, HT-400TM, Urethane, Standard Service(Brown)	9	3	316.21006.PREM	316.21006.PREM	316.22049.PREM
Seat Valve, HT-400TM, Tapered	10	3	316.21008.PREM	316.21008.PREM	316.210047.PREM
O-ring, 90 Duro	11	3	8.34037.PREM	8.34037.PREM	8.34041.PREM


Suction Valve Subassembly
Plunger Size
	Loc	Qty	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Retainer, Stop and Spring, HT-400TM, Mach. Cast	1	3	316.22977.PREM	316.22977.PREM	316.22242.PREM	316.25840.PREM	316.25840.PREM
Boot, Suction and Stop, HT-400TM	2	6	316.25233.PREM	316.25233.PREM	316.25233.PREM	316.25233.PREM	316.25233.PREM
Spring, Lock, HT-400	3	3	316.2125.PREM	316.2125.PREM	316.22252.PREM	316.22253.PREM	316.22253.PREM
Liner, Two Piece Bushing, Valve Guide, HT-400TM, Brass	4	6	316.22005.PREM	316.22005.PREM	316.22005.PREM	316.22007.PREM	316.22007.PREM
Insert,Two Piece Bushing, Valve Guide, Special,HT-400TM	5	6	316.22004.PREM	316.22004.PREM	316.22004.PREM	316.22006.PREM	316.22006.PREM
Retainer Guide Bushing, HT-400, Tapered Seat Bore	11	3	316.21096.PREM	316.21096.PREM	316.23953.PREM	316.24043.PREM	316.24043.PREM


Plunger/cylender Head Cover Subassembly
Plunger Size
	Loc	Qty	3-3/8 inch	4-inch	4-1/2 inch	5-inch	6-inch
Retainer, Cover HT-400TM	1	6	316.2102.PREM	316.2102.PREM	316.2202.PREM	316.2502.PREM	316.2506.PREM
Cover, Cylinder Head, HT-400TM	2	3	316.2107.PREM	316.2107.PREM	316.2207.PREM	316.2407.PREM	316.2507.PREM
Gasket, 4 Discharge Valve & Cylinder Head Cover	3	6	316.21052.PREM	316.21052.PREM	316.22052.PREM	316.25052.PREM	316.25074.PREM
Ring, Spacer, Discharge Valve & Cylinder Head Cover	4	6	316.21051.PREM	316.21051.PREM	316.22051.PREM	316.25051.PREM	316.25073.PREM
Nose, Plunger, HT-400TM	5	3	316.2131.PREM	316.2231.PREM	316.2331.PREM	316.2331.PREM	316.2331.PREM
Seal, Plunger Nose Assembly, HT-400TM	6	3	316.2130.PREM	316.2230.PREM	316.2330.PREM	316.2330.PREM	316.2330.PREM
Plunger, Hard Surface, L-Spacer, HT-400TM	7	3	316.21026.PREM	316.22294.PREM	316.23085.PREM	316.24296.PREM	316.25162.PREM
Tie Rod, Plunger, HT-400TM	8	3	316.21028.PREM	316.21028.PREM	316.21028.PREM	316.25165.PREM	316.25165.PREM
Adapter, Pushrod, HT-400TM, Two Piece Nose	9	3	316.21059.PREM	316.22302.PREM	316.23089.PREM	316.24336.PREM	316.25172.PREM


Fluid-end/flange discharge section subassembly
Plunger Size
	Loc	Qty	3-3/8 inch	4-inch	4-1/2 inch
Flange, discharge, HT-400TM, BLANK	1	1		316.22980.PREM	316.22980.PREM
Flange, discharge, HT-400TM, CURVED, Rright Hand	1a	1	316.21676.PREM	316.23019.PREM	316.23019.PREM
Flange, discharge, HT-400TM, CURVED, Left Hand	1b	1	316.21677.PREM	316.23017.PREM	316.23017.PREM
Seal, Discharge passage,HT-400TM	2	6	315.27117.PREM	316.2547.PREM	316.2547.PREM
Nut, 1-14NF, Internal Wrenching, 1.03 TL	3	4	316.11621.PREM	316.11621.PREM	316.11621.PREM
Stud, HT-400TM Fluid End To Thick Discharge Flange	4	4	316.23013.PREM		316.23013.PREM
Bolt, Tie, 1.375-12 UNF×32.4 in.,Top, Fluid End, HT-400TM, TC	5	1	316.27488.PREM	316.27488.PREM	316.27488.PREM
Nut, Top Tie Bolt, HT-400TM, TC	6	2	316.25501.PREM	316.25501.PREM	316.25501.PREM
Washer, Hardened,2.31 O.D ×1.43I.D.,For Top Tie Boldt,	7	2	316.22493.PREM	316.22493.PREM	316.22493.PREM
Spacer, Inner, Discharge Passage Seal,HT-400TM	8	2	316.2145.PREM	316.2545.PREM	316.2545.PREM
Fluid End Section, HT-400TM PUMP,Not Sleeved	9	3	316.21951.PREM	316.22982.PREM	316.23951.PREM
Nut, Elastic, Stop,3/4-in.,16 NF	10	2	70.32760.PREM		70.32760.PREM
